Scale: Reflactive Index (nD), Brix, One another concentration, Temperature
Measurement item:
Reflactive Index (nD)
Brix (temperature compensation for sucrose)
One another concentration (temperature compensation specific for the solute) and temperature
Measurement Range:
Refractive index (nD) : 1.31700 to 1.51000
Brix : 0.00 to 85.00%
Resolution:
Refractive index (nD) : 0.0001 or 0.00001
Brix : 0.1 or 0.01% (by selection)
Measurement Accuracy:
Refractive index (nD) : ±0.0001
Brix : ±0.1%
Light source: LED
Alarm output: Open-collector output for high and low limit settings (alarm output)
Output: RS-232C, DC4 to 20mA
Measurement Temperature: 5 to 100℃
Materials:
Prism – synthetic sapphire
Prism O-ring – FEP, PTFE
Flange O-ring – PTFE
Prism stage – SUS316
Cable: Cable between the detection & display units: 15m standard (extension available up to 200m)
Power Supply: AC 100 to 240V, 50 / 60Hz
International Protection Class:
Detection section : IP66/IP67
Calculation Display section : IP65
Dimensions & Weight:
Detection section : 25×29.73×25cm, 12.3kg
Calculation Display section : 19.2×10×24cm, 3.3kg
Power consumption: 30VA
Pressure-resistant: 1.0MPa (Detection section)
