Key features and benefits of Coin Cell HT Module:
- The only dedicated calorimeter for coin cell measurement up to 300°C.
- Use unique differential measuring principle for improved stability and sensitivity to capture even weak heat signal from coin cell.
- Characterize coin cell as a whole to mimic the cell performance in real world
- Easy to use and can run both isothermal charging/discharging method and scanning method for complete characterization of coin cell
Temperature range:
RT to 300°C
Temperature resolution:
0.001 K
Heating rate:
0.01 to 5 K/min
Coin cell size (Diameter/Thickness):
5 to 30 mm / 1 to 5 mm
RMS noise:
10 µW
Energy measurement accuracy:
<3%
Energy measurement reproducibility:
1%
Standard crucible capacity:
500 µl
DSC measuring range:
Up to 370 mW
Modes of operation:
Isothermal, Constant heating, DSC
Number of sample cell / reference cell:
1 / 1
Max. current:
500 mA
Internal wiring (force):
24 awg (0.15 mm)
Internal wiring (sense):
24 awg (0.15 mm)
Footprint without battery cycler (inch) (cm):
19.75 x 15.75 x 22.2550 x 40 x 57
Software
NETZSCH Proteus® Measurement Software:
Proven Technology Leader
- Software automatically customizes itself to the instrument and application
- Intuitive Windows set-up of testing methods with input checks to reduce typos
- Methods can be saved and recalled for later use
- On-line help, comprehensive and easy to understand, available throughout the software
- Data is automatically saved to hard-drive throughout the run
- Intelligent firmware monitors the status and health of key operating sensors and active components
- Safety integrated with hardware and firmware controls
- Seamless integration of data files to Proteus® Analysis, NETZSCH Advanced Software Tools or 3rd party software
Applications
The Coin Cell module can be used for a variety of applications in coin cell study:
-
- Performance evaluation
- Energy efficiency calculation
- Safety study
- Cell components investigation
